HYSF DLSE02-F is a robust female locking dummy cap with split petal design and delrin body. IP68 rated, 60 MPa tested, dedicated for protecting unused male ports in split petal series connectors for ROVs, thrusters, sensors and deepsea installations up to 6000 m.
The HYSF DLSE02-F is a dedicated female locking dummy cap with innovative split petal design that securely seals and protects exposed male split petal connectors from seawater intrusion, biofouling and mechanical damage. Its black delrin body with threaded locking sleeve provides a complete pressure-tight mechanical barrier with no electrical connection.
Precision-molded from high-strength, UV-resistant delrin (POM) with integrated O-ring seal and captive threaded locking ring. The split petal structure allows easy installation even in confined spaces or with limited access.
Essential for maintaining system integrity on male split petal ports when temporarily unmated, preventing contamination in harsh subsea environments. ISO9001-2015 certified with 100 MPa burst rating.
Model: DLSE02-F
Brand: HYSF
Type: Split Petal Female Locking Dummy Cap
Gender: Female (Non-Electrical)
Contact: None (Sealing Only)
Housing Material: Delrin (POM) + Stainless Thread
Sealing: Single O-Ring + Face Seal
Body Diameter: 30.2 mm
Total Length: 35.5 mm
Locking: Threaded Sleeve
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: Split Petal Male Port Protection, Dummy Cap for Split Petal Series, ROV/Sensor Port Sealing
Certification: ISO9001-2015
Compatibility: Split Petal Series Male Ports
Place of Origin: Guangdong, China
