HYSF LPMBH/IL4M/F Micro Flange-Mount 4-Pin Underwater Connector with Triple O-Ring Seal

Product Description

The HYSF LPMBH/IL4M/F Micro is a successfully customized micro underwater connector with a low-profile square flange and integrated 4-pin right-angle inline design. Engineered with **three redundant O-ring seals** (face, radial, and axial) for triple-redundant waterproofing—perfect for mission-critical miniature ROV control modules, AUV sensor interfaces, and compact deepsea instruments where failure is not an option.

Precision-machined from marine-grade aluminum (anodized) or optional titanium, with gold-plated brass contacts and red PTFE-insulated flying leads. The triple-seal architecture exceeds standard IP68 requirements and has been pressure-tested to 10,000 PSI (689 Bar), ensuring zero leakage at full ocean depth (>6000 m). Flange includes four M3 mounting holes for secure panel integration.

This micro flange connector was developed for extreme size constraints while maintaining maximum sealing reliability. HYSF offers full customization in pin count (2–6), seal material, flange geometry, and lead configuration. ISO9001-2015 certified and field-validated in ultra-compact subsea systems.

Product Parameter

Model: LPMBH/IL4M/F Micro

Brand: HYSF

Type: Micro Flange-Mount Underwater Connector with Triple O-Ring Seal

Gender: Female Bulkhead → Male Inline Compatible

Pins: 4 Pin (2–6 Pin Custom)

Sealing: Triple Redundant O-Rings (Face + Radial + Axial)

Flange: Square, 4x M3 Mounting Holes

Housing Material: Hard-Anodized Aluminum (Optional Titanium)

Contact Material: Gold-plated Brass

Leads: Red PTFE-Insulated, Pre-Stripped & Labeled

Waterproof Rating: IP68+ (Triple-Sealed)

Mated Pressure Rating: Up to 10,000 PSI (689 Bar)

Depth Rating: Up to 6000m+

Interface Type: AC/DC Signal & Low-Power Compatible

Application: Micro-ROVs, AUV Sensor Pods, Compact Control Modules, Deepsea Mini Instruments

Certification: ISO9001-2015

Customization: Pin count, O-ring material (Viton/Nitrile), flange size, lead length/color

Place of Origin: Guangdong, China
