HYSF MCBH10F is a miniature 10-pin female bulkhead connector with Ø15.7 mm body. IP68 rated, 60 MPa tested, designed for ultra-high-density micro-ROVs, AUV multi-sensor hubs, 1000BASE-T + power feedthroughs, and compact deepsea instrumentation up to 6000m.
The HYSF MCBH10F delivers an unmatched 10 electrical channels in the same Ø15.7 mm Micro footprint, providing the highest pin density available in any subsea connector under 20 mm diameter. With only 40.7 mm mated length, it is the ultimate solution for space-critical applications requiring Gigabit Ethernet plus multiple power/sensor lines.
Precision-machined from marine-grade 316L stainless steel with gold-plated brass sockets, double O-ring sealing, and includes hex nut + washer for secure panel mounting. Pre-terminated with 10 color-coded PTFE leads for easy internal wiring.
Ideal for advanced observation-class ROVs, deep-rated multi-sensor pods, Ethernet + power distribution panels, and compact AUV pressure housings. ISO9001-2015 certified with 100% hyperbaric testing.
Model: MCBH10F
Brand: HYSF
Type: Miniature 10-Core Female Bulkhead Connector
Gender: Female
Pin Count: 10
Contact Material: Gold-plated Brass
Current Rating: 10A per Pin
Voltage Rating: 600V AC/DC
Housing Material: 316L Stainless Steel
Sealing: Double O-Ring
Body Diameter: Ø15.7 mm
Mated Length: 40.7 mm
Mounting: M16 Thread with Hex Nut & Washer
Cable: Pre-terminated 10-color PTFE Leads
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: Gigabit Ethernet + Power Penetrators, Ultra-High-Density ROV Ports, AUV Multi-Sensor Bulkheads, Deepsea Feedthrough
Certification: ISO9001-2015
Compatibility: Subconn Micro Series 10-pin / MCIL10M
Place of Origin: Guangdong, China
