HYSF MCBH13F Miniature 13-core female base Underwater Connector

Product Description

The HYSF MCBH13F represents the pinnacle of the Micro series — an astonishing 13 independent channels packed into the same Ø15.7 mm envelope, delivering the highest pin-count ever achieved in any sub-20 mm wet-mate connector worldwide. At only 40.7 mm mated length, it is the definitive solution for the most complex Gigabit Ethernet + power + sensor penetrations where space is at an absolute premium.

Precision-machined marine-grade 316L stainless steel with gold-plated brass sockets, double O-ring sealing, and supplied with hex nut + washer for secure panel mounting. Pre-terminated with 13 color-coded PTFE leads for rapid internal wiring.

Essential for next-generation observation-class ROVs, ultra-compact AUV pressure housings, deep-rated multi-sensor hubs, and Ethernet + power distribution panels requiring maximum channel density. ISO9001-2015 certified with 100% hyperbaric testing.

Product Parameter

Model: MCBH13F

Brand: HYSF

Type: Miniature 13-Core Female Bulkhead Connector

Gender: Female

Pin Count: 13

Contact Material: Gold-plated Brass

Current Rating: 10A per Pin

Voltage Rating: 600V AC/DC

Housing Material: 316L Stainless Steel

Sealing: Double O-Ring

Body Diameter: Ø15.7 mm

Mated Length: 40.7 mm

Mounting: M16 Thread with Hex Nut & Washer

Cable: Pre-terminated 13-color PTFE Leads

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: Ultimate-Density Gigabit Ethernet + Multi-Power Penetrators, Extreme ROV Ports, AUV Sensor Hubs, Deepsea Feedthrough

Certification: ISO9001-2015

Compatibility: Subconn Micro Series 13-pin / MCIL13M

Place of Origin: Guangdong, China
