HYSF MCBH16F Miniature 16-core female base Underwater Connector

Product Description

The HYSF MCBH16F pushes the Micro series beyond conventional limits — an incredible 16 independent channels in the same Ø15.7 mm envelope, making it the highest pin-count female bulkhead connector under 20 mm worldwide. At only 40.7 mm mated length, it is the ultimate solution for the most complex Gigabit Ethernet + power + sensor penetrations where every millimeter counts.

Precision-machined marine-grade 316L stainless steel with gold-plated brass sockets, double O-ring sealing, and supplied with hex nut + washer for secure panel mounting. Pre-terminated with 16 color-coded PTFE leads for rapid internal wiring.

Indispensable for next-generation observation-class ROVs, ultra-compact AUV pressure housings, deep-rated multi-sensor hubs, and Ethernet + power distribution panels requiring absolute maximum channel density. ISO9001-2015 certified with 100% hyperbaric testing.

Product Parameter

Model: MCBH16F

Brand: HYSF

Type: Miniature 16-Core Female Bulkhead Connector

Gender: Female

Pin Count: 16

Contact Material: Gold-plated Brass

Current Rating: 10A per Pin

Voltage Rating: 600V AC/DC

Housing Material: 316L Stainless Steel

Sealing: Double O-Ring

Body Diameter: Ø15.7 mm

Mated Length: 40.7 mm

Mounting: M16 Thread with Hex Nut & Washer

Cable: Pre-terminated 16-color PTFE Leads

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: Maximum-Density Gigabit Ethernet + Multi-Power Penetrators, Extreme ROV Ports, AUV Sensor Hubs, Deepsea Feedthrough

Certification: ISO9001-2015

Compatibility: Subconn Micro Series 16-pin / MCIL16M

Place of Origin: Guangdong, China
