HYSF MCDC10F is a compact 10-pin female dummy plug with tapered PU body. IP68 rated, 60 MPa tested, specifically designed for sealing unused male 10-pin ports on ultra-high-density micro-ROVs, AUV multi-sensor panels, Gigabit Ethernet + power ports and deepsea instrumentation up to 6000m.
The HYSF MCDC10F is a precision 10-core female dummy plug that reliably protects exposed male 10-pin connectors from seawater intrusion, biofouling and impact damage. Its conical black polyurethane body (123 mm total length, Ø15.7 mm max) inserts directly into MCIL10M or MCBH10M ports, forming a full-pressure mechanical seal with zero electrical connection.
Injection-molded from high-durometer UV-stabilized PU with embedded stainless steel retention clip and integrated 2 mm tether loop. Triple internal O-rings lock securely onto the host connector shoulder while the large hex grip enables easy hand-tightening even with thick gloves.
Essential for maintaining system integrity on ultra-high-density Gigabit-Ethernet + power systems, multi-sensor arrays, deep-rated battery packs and complex payloads when ports are temporarily unmated. ISO9001-2015 certified with 100 MPa burst rating and 500-hour UV resistance.
Model: MCDC10F
Brand: HYSF
Type: Miniature 10-Core Female Dummy Plug
Gender: Female (Non-Electrical)
Pin Count: 10 Dummy Sockets
Contact Material: None (Sealing Only)
Housing Material: Polyurethane + 316L Stainless Clip
Sealing: Triple O-Ring on Tapered Nose
Body Diameter: Ø15.7 mm (Max)
Total Length: 123 mm
Grip Section: Large Hex
Tether: Integrated 2 mm Stainless Loop
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: ROV 10-pin Male Port Protection, AUV Gigabit + Power Blanking, Multi-Sensor Dummy Caps
Certification: ISO9001-2015
Compatibility: MCIL10M / MCBH10M Male Ports
Place of Origin: Guangdong, China
