HYSF MCDC25F Miniature 25-core female dummy plug Underwater Connector

Product Description

The HYSF MCDC25F is the highest pin-count female dummy plug ever produced, reliably protecting exposed male 25-pin connectors from seawater intrusion, biofouling and mechanical damage. Its conical black polyurethane body (Ø15.7 mm max) inserts directly into MCIL25M or MCBH25M ports, forming a full-pressure mechanical seal with zero electrical connection.

Injection-molded from high-durometer UV-stabilized PU with embedded stainless steel retention clip and integrated 2 mm tether loop. Triple internal O-rings lock securely onto the host connector shoulder while the large hex grip enables easy hand-tightening even with thick gloves.

Essential for maintaining system integrity on maximum-channel-count Gigabit-Ethernet + multi-power systems, deep-rated sensor arrays, battery packs and complex payloads when ports are temporarily unmated. ISO9001-2015 certified with 100 MPa burst rating and 500-hour UV resistance.

Product Parameter

Model: MCDC25F

Brand: HYSF

Type: Miniature 25-Core Female Dummy Plug

Gender: Female (Non-Electrical)

Pin Count: 25 Dummy Sockets

Contact Material: None (Sealing Only)

Housing Material: Polyurethane + 316L Stainless Clip

Sealing: Triple O-Ring on Tapered Nose

Body Diameter: Ø15.7 mm (Max)

Total Length: 131 mm

Grip Section: Large Hex

Tether: Integrated 2 mm Stainless Loop

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: ROV 25-pin Male Port Protection, AUV Maximum-Density Blanking, Extreme High-Density Dummy Caps

Certification: ISO9001-2015

Compatibility: MCIL25M / MCBH25M Male Ports

Place of Origin: Guangdong, China
