HYSF MCDC8M is a low-profile 8-pin male dummy plug with tapered PU cap. IP68 rated, 60 MPa tested, dedicated for protecting unused female 8-pin ports on Gigabit-Ethernet ROVs, high-density AUV panels, deepsea switch modules and multi-channel sensor hubs up to 6000m.
The HYSF MCDC8M is a robust 8-core male dummy plug designed to fully seal and protect open female 8-pin receptacles in harsh subsea environments. Its streamlined black polyurethane cap (74 mm total length, Ø15.7 mm max) slides over MCIL8F or MCBH8F ports, creating a complete pressure-tight barrier with no electrical connection.
Molded from abrasion-resistant, UV-stabilized PU with integrated stainless steel tether eye and triple internal O-rings. The 18.5 mm hex grip enables tool-free installation even with gloved hands, while the captive tether eye prevents loss during ROV operations.
Critical for safeguarding high-channel-count ports on Gigabit-Ethernet systems, deepsea camera housings, multi-sensor arrays and battery modules from biofouling and debris. ISO9001-2015 certified with 100 MPa over-pressure validation and 2000-hour salt-spray resistance.
Model: MCDC8M
Brand: HYSF
Type: Miniature 8-Core Male Dummy Plug
Gender: Male (Non-Electrical)
Pin Count: 8 Dummy Pins
Contact Material: None (Sealing Only)
Housing Material: Polyurethane + 316L Stainless Tether Eye
Sealing: Triple O-Ring on Tapered Shaft
Body Diameter: Ø15.7 mm (Max)
Total Length: 74 mm
Grip Section: 18.5 mm Hex
Tether: Integrated 1.5 mm Stainless Eyelet
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: ROV 8-pin Female Port Blanking, AUV Gigabit Ethernet Protection, Multi-Sensor Dummy Caps
Certification: ISO9001-2015
Compatibility: MCIL8F / MCBH8F Female Ports
Place of Origin: Guangdong, China
