HYSF MCIL10M is an ultra-compact 10-pin male inline cable connector with Ø15.7 mm PU overmold. IP68 rated, 60 MPa tested, ideal for Gigabit Ethernet + power tethers, high-density micro-ROV umbilicals, AUV multi-sensor chains, and deepsea inline splicing up to 6000m.
The HYSF MCIL10M packs a class-leading 10 channels into the same Ø15.7 mm Micro envelope, delivering the highest pin density available in any male inline connector under 20 mm. Its compact 19 mm hex grip and threaded locking sleeve guarantee secure mating even in extremely confined spaces.
Precision-machined 316L stainless steel insert with gold-plated brass pins, fully encapsulated in black polyurethane with integrated strain relief. Pre-terminated with 10 × 24 AWG color-coded PTFE leads. Fully supports 1000BASE-T Ethernet (two shielded twisted pairs) plus 6 additional pins for power or sensors.
Perfect for next-generation observation-class ROVs, deepsea instrumentation, and Ethernet + power payloads where minimum diameter and maximum channel count are non-negotiable. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.
Model: MCIL10M
Brand: HYSF
Type: Miniature 10-Core Male Inline Cable
Gender: Male
Pin Count: 10
Contact Material: Gold-plated Brass
Current Rating: 10A per Pin
Voltage Rating: 600V AC/DC
Housing Material: 316L Stainless Steel + PU Overmold
Sealing: Double O-Ring + Face Seal
Body Diameter: Ø15.7 mm
Grip Length: 19 mm
Cable: 10 × 24 AWG PTFE Leads (10-color coded)
Overmold: Black Polyurethane (PU)
Locking: Threaded Sleeve
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: Gigabit Ethernet + Power Extensions, ROV Umbilicals, AUV Sensor Chains, High-Density Splicing
Certification: ISO9001-2015
Compatibility: MCBH10F / MCIL10F Females
Place of Origin: Guangdong, China
