HYSF MCIL13F Miniature 13-core female cable Underwater Connector

Product Description

The HYSF MCIL13F achieves an unprecedented 13 channels in the ultra-compact Ø15.7 mm Micro envelope — the highest pin-count ever realized in any wet-mate inline connector under 20 mm. Its 28 mm hex grip and tapered nose guarantee fast, reliable mating even in the tightest spaces.

Precision-machined 316L stainless steel insert with gold-plated brass sockets, fully encapsulated in black polyurethane with integrated strain relief. Pre-terminated with 13 color-coded PTFE leads. Supports 1000BASE-T Ethernet (two shielded twisted pairs) while leaving 9 pins for power or additional sensors.

The ultimate choice for next-generation observation-class ROVs, deepsea instrumentation, and Ethernet + multi-power payloads where absolute minimum diameter and maximum channel count are mandatory. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.

Product Parameter

Model: MCIL13F

Brand: HYSF

Type: Miniature 13-Core Female Inline Cable

Gender: Female

Pin Count: 13

Contact Material: Gold-plated Brass

Current Rating: 10A per Pin

Voltage Rating: 600V AC/DC

Housing Material: 316L Stainless Steel + PU Overmold

Sealing: Double O-Ring + Face Seal

Body Diameter: Ø15.7 mm

Grip Length: 28 mm

Cable: 13 × 24 AWG PTFE Leads (13-color coded)

Overmold: Black Polyurethane (PU)

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: Ultimate-Density Gigabit Ethernet + Multi-Power Extensions, Extreme ROV Umbilicals, AUV Sensor Chains, Deepsea Splicing

Certification: ISO9001-2015

Compatibility: MCBH13M / MCIL13M Males

Place of Origin: Guangdong, China
