HYSF MCIL16M Miniature 16-core male cable Underwater Connector

Product Description

The HYSF MCIL16M pushes the Micro series to its extreme limit — an astonishing 16 independent channels inside the ultra-compact Ø15.7 mm envelope, making it the highest pin-count male wet-mate inline connector under 20 mm ever produced. Its compact 19 mm hex grip and threaded locking sleeve ensure secure mating even in the most confined spaces.

Precision-machined 316L stainless steel insert with gold-plated brass pins, fully encapsulated in black polyurethane with integrated strain relief. Pre-terminated with 16 color-coded PTFE leads. Fully supports 1000BASE-T Ethernet (two shielded twisted pairs) plus 12 additional pins for power or sensors.

The definitive choice for next-generation observation-class ROVs, deepsea instrumentation, and Ethernet + multi-power payloads where absolute minimum diameter and maximum channel count are non-negotiable. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.

Product Parameter

Model: MCIL16M

Brand: HYSF

Type: Miniature 16-Core Male Inline Cable

Gender: Male

Pin Count: 16

Contact Material: Gold-plated Brass

Current Rating: 10A per Pin

Voltage Rating: 600V AC/DC

Housing Material: 316L Stainless Steel + PU Overmold

Sealing: Double O-Ring + Face Seal

Body Diameter: Ø15.7 mm

Grip Length: 19 mm

Cable: 16 × 24 AWG PTFE Leads (16-color coded)

Overmold: Black Polyurethane (PU)

Locking: Threaded Sleeve

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: Maximum-Density Gigabit Ethernet + Multi-Power Extensions, Extreme ROV Umbilicals, AUV Sensor Chains, Deepsea Splicing

Certification: ISO9001-2015

Compatibility: MCBH16F / MCIL16F Females

Place of Origin: Guangdong, China
