HYSF MCIL/MCIL8M Custom Coiled Water-Tight Cable Assembly (8-Pin, Stretchable)MCIL8M-Coiled

Product Description

The HYSF MCIL8M-Coiled is a fully customized 8-pin underwater cable assembly featuring dual inline male connectors (MCIL) joined by a high-flex coiled polyurethane jacket. Designed for dynamic subsea applications, the coil extends smoothly under tension and retracts to minimize slack—perfect for ROV umbilical management, portable sensor systems, and space-constrained deepsea tools.

Built with marine-grade polyurethane overmolding, gold-plated brass contacts, and reinforced strain relief, it ensures reliable AC/DC transmission in harsh saltwater environments. Rated IP68 and pressure-tested to 10,000 PSI (689 Bar), it supports dependable operation at depths beyond 6000 meters with full mating compatibility to Subconn® MCBH/MCIL series.

This stretchable coiled solution was engineered to client specifications for reduced tangling, easy storage, and dynamic reach. HYSF offers full customization in pin count, coil length (relaxed/extended), cable diameter, and connector gender. ISO9001-2015 certified and proven in real-world ROV and AUV deployments.

Product Parameter

Model: MCIL8M-Coiled

Brand: HYSF

Type: Custom Coiled Water-Tight Cable Assembly

Connectors: MCIL8M → MCIL8M (Inline Male to Male)

Pins: 8 Pin

Cable Jacket: High-Flex Polyurethane, Coiled

Coil Behavior: Retractable, Stretchable (Custom Relaxed/Extended Length)

Housing Material: Acetal (POM) or Stainless Steel

Contact Material: Gold-plated Brass

Waterproof Rating: IP68

Mated Pressure Rating: Up to 10,000 PSI (689 Bar)

Depth Rating: Up to 6000m+

Interface Type: AC/DC Compatible

Application: ROV Tethers, Dynamic Sensor Links, Portable Subsea Tools, AUV Extensions

Certification: ISO9001-2015

Customization: Pin count, coil dimensions, cable color, connector type/gender, overmolding

Compatibility: Full Subconn® MCIL/MCBH interchangeability

Place of Origin: Guangdong, China
