HYSF SFCOEDC4M High current 4-core male plug Underwater Connector

Product Description

The HYSF SFCOEDC4M delivers full 1000BASE-T Gigabit Ethernet combined with power in a compact plug profile with tapered PU overmold, ideal for direct mating to bulkhead receptacles in constrained spaces. Only 19 mm grip length with robust strain relief.

Precision 316L stainless steel insert with gold-plated brass pins, fully encapsulated in black polyurethane. Pre-terminated with 4 × mixed AWG PTFE leads (typically 2 power + 2 twisted pairs for Ethernet).

The preferred solution for Ethernet-enabled thruster plugs, high-resolution camera connections with power, hybrid sensor interfaces and demanding subsea systems requiring combined high-speed data and power. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.

Product Parameter

Model: SFCOEDC4M

Brand: HYSF

Type: High Current 4-Core Male Plug

Gender: Male

Pin Count: 4

Contact Material: Gold-plated Brass

Current Rating: 30A on power pins, 8A on data pins

Voltage Rating: 600V AC/DC

Housing Material: 316L Stainless Steel + PU Overmold

Sealing: Double O-Ring + Face Seal

Body Diameter: 31 mm

Grip Length: 19 mm

Cable: 4 × mixed AWG PTFE Leads (Gigabit Ethernet + Power capable)

Overmold: Black Polyurethane (PU)

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: Gigabit Ethernet + Power Plugs, Ethernet Thruster Connections, High-Resolution Camera Feeds with Power, Deepsea Hybrid Data/Power Mating

Certification: ISO9001-2015

Compatibility: Corresponding High-Current Female Receptacles

Place of Origin: Guangdong, China
