HYSF SFCOEIL6M High current 6-core male cable Underwater Connector

Product Description

The HYSF SFCOEIL6M delivers 6 channels including Gigabit Ethernet + dual power/sensor in a compact inline profile with tapered PU overmold, enabling reliable hybrid cable termination and splicing in constrained spaces. Only 19 mm grip length with robust strain relief.

Precision 316L stainless steel insert with gold-plated brass pins, fully encapsulated in black polyurethane. Pre-terminated with 6 × mixed AWG PTFE leads. Typical configuration: 1000BASE-T Gigabit Ethernet (4 pins) + 2 additional power/sensor lines.

The ultimate solution for multi-channel Ethernet-enabled thruster umbilicals, advanced camera feeds with power, hybrid sensor/actuator chains and deepsea hybrid cables requiring maximum functionality in minimal cross-section. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.

Product Parameter

Model: SFCOEIL6M

Brand: HYSF

Type: High Current 6-Core Male Inline Cable

Gender: Male

Pin Count: 6

Contact Material: Gold-plated Brass

Current Rating: 30A on power pins, 8A on data pins

Voltage Rating: 600V AC/DC

Housing Material: 316L Stainless Steel + PU Overmold

Sealing: Double O-Ring + Face Seal

Body Diameter: 31 mm

Grip Length: 19 mm

Cable: 6 × mixed AWG PTFE Leads

Overmold: Black Polyurethane (PU)

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: Gigabit Ethernet + Dual Power/Sensor Ultra-Miniature Tethers, Multi-Channel Thruster Umbilicals, Advanced Camera Chains with Power, Deepsea High-Density Hybrid Inline Splicing

Certification: ISO9001-2015

Compatibility: Corresponding High-Current Female Connectors

Place of Origin: Guangdong, China
