HYSF SFCOEILRA3M is a high-current 3-pin male right-angle (L-shape) inline cable connector with PU overmold. IP68 rated, 60 MPa tested, designed for space-constrained hybrid power + control connections in ROVs, thrusters, actuators and deepsea applications up to 6000 m where straight connectors won't fit.
The HYSF SFCOEILRA3M features a compact 90° right-angle design with tapered PU overmold, perfect for tight installation spaces while maintaining full high-current capability with additional control channel. 51 mm overall length with integrated strain relief.
Precision 316L stainless steel insert with gold-plated brass pins, fully encapsulated in black polyurethane. Pre-terminated with 3 × 14 AWG PTFE leads (typically 2 high-power + 1 control/signal).
Ideal for right-angle thruster power + control connections, actuator interfaces, hybrid battery umbilicals and any subsea application requiring combined high current and signal in confined or angled routing. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.
Model: SFCOEILRA3M
Brand: HYSF
Type: High Current 3-Core Male Right-Angle Inline Cable
Gender: Male
Pin Count: 3
Contact Material: Gold-plated Brass
Current Rating: 50A on power pins, 10A on signal pin
Voltage Rating: 600V AC/DC
Housing Material: 316L Stainless Steel + PU Overmold
Sealing: Double O-Ring + Face Seal
Body Diameter: 31 mm
Overall Length: 51 mm
Cable: 3 × 14 AWG PTFE Leads
Overmold: Black Polyurethane (PU)
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: Right-Angle Thruster Power + Control, Low-Profile Actuator Interfaces, Hybrid Battery Umbilicals, Space-Constrained High-Power + Signal Tethers
Certification: ISO9001-2015
Compatibility: Corresponding High-Current Female Connectors
Place of Origin: Guangdong, China
