HYSF SFCXIL3F is an ultra-compact 3-pin female inline cable connector with PU overmold. IP68 rated, 60 MPa tested, ideal for power + RS485/RS232 control tethers in the most space-restricted micro-ROVs, miniature AUVs, ultra-thin umbilicals and deepsea inline splicing up to 6000 m.
The HYSF SFCXIL3F delivers 3 channels in the smallest possible inline profile with tapered PU overmold, enabling seamless cable termination and splicing where space is extremely limited. Only 44 mm grip length with integrated strain relief.
Precision 316L stainless steel insert with gold-plated brass sockets, fully encapsulated in black polyurethane. Pre-terminated with 3 × 20 AWG PTFE leads. Typical configuration: 2 power pins + 1 differential pair for RS485/RS232 half-duplex communication.
The definitive choice for ultra-miniature ROV control umbilicals, compact pan-tilt/sonar feeds, micro-actuator interfaces and deepsea hybrid cables requiring combined power + data in minimal cross-section. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.
Model: SFCXIL3F
Brand: HYSF
Type: Ultra Small 3-Core Female Inline Cable
Gender: Female
Pin Count: 3
Contact Material: Gold-plated Brass
Current Rating: 15A per Pin
Voltage Rating: 600V AC/DC
Housing Material: 316L Stainless Steel + PU Overmold
Sealing: Double O-Ring + Face Seal
Body Profile: 16 × 14 mm
Grip Length: 44 mm
Cable: 3 × 20 AWG PTFE Leads (color-coded)
Overmold: Black Polyurethane (PU)
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: Power + RS485/RS232 Ultra-Miniature Tethers, Micro PTZ/Sonar Umbilicals, Compact Actuator Control Chains, Deepsea Hybrid Inline Splicing
Certification: ISO9001-2015
Compatibility: SFCXBHRA3 Males
Place of Origin: Guangdong, China
