HYSF SFHPCDBH6M High power 6-core male seat Underwater Connector

Product Description

The HYSF SFHPCDBH6M delivers full 1000BASE-T Gigabit Ethernet combined with dual high power/sensor channels in a robust large-diameter bulkhead mount design, ideal for extreme hybrid data + power penetrations in heavy-duty subsea equipment.

Precision-machined 316L stainless steel body with gold-plated brass pins, double O-ring sealing, and supplied with stainless mounting nut + washer. Pre-terminated with 6 × heavy-gauge PTFE leads (typically 4 for Gigabit Ethernet + 2 high-power/sensor).

The preferred solution for high-power Ethernet-enabled thruster penetrators, heavy winch ports with data, large hybrid battery interfaces and demanding subsea systems requiring combined high-speed data and substantial power/sensor channels. ISO9001-2015 certified with 100% hyperbaric testing.

Product Parameter

Model: SFHPCDBH6M

Brand: HYSF

Type: High Power 6-Core Male Bulkhead Connector

Gender: Male

Pin Count: 6

Contact Material: Gold-plated Brass

Current Rating: 100A on power pins, 8A on data pins

Voltage Rating: 1000V AC/DC

Housing Material: 316L Stainless Steel

Sealing: Double O-Ring

Body Diameter: 86 mm

Body Length: 29.6 mm

Mounting: Threaded with Nut & Washer

Cable: Pre-terminated 6 × heavy-gauge PTFE Leads (Gigabit Ethernet + High Power capable)

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: High-Power Gigabit Ethernet + Dual Power/Sensor Penetrators, Heavy Thruster Ports with Data, Winch Power + Ethernet, Deepsea Extreme Hybrid Data/Power Distribution

Certification: ISO9001-2015

Compatibility: Corresponding High-Power Female Plugs

Place of Origin: Guangdong, China
