HYSF SFLPBH13M is an extreme-density flat 13-pin male bulkhead connector with 44×24 mm footprint. IP68 rated, 60 MPa tested, engineered for Gigabit Ethernet + high-power + multi-sensor/actuator feedthroughs on the most space-constrained AUVs, micro-ROVs, advanced manipulators and thin pressure housings up to 6000 m.
The HYSF SFLPBH13M pushes the Flat series to its limit with 13 channels in an ultra-thin profile only 21 mm thick, delivering maximum functionality where panel space is at an absolute premium.
Precision-machined 316L stainless steel body with gold-plated brass pins, double O-ring sealing, and supplied with stainless mounting nut + washer. Pre-terminated with 13 color-coded PTFE leads. Standard layout: 1000BASE-T Gigabit Ethernet (4 pins) + high-current power pair + remaining 7 pins for RS485/RS232, sensors or actuators.
The ultimate choice for next-generation ultra-compact ROVs, 8K/12K imaging systems, multi-function manipulators and highly integrated deepsea payloads requiring maximum signal count in minimal volume. ISO9001-2015 certified with 100% hyperbaric testing.
Model: SFLPBH13M
Brand: HYSF
Type: Flat 13-Core Male Bulkhead Connector
Gender: Male
Pin Count: 13
Contact Material: Gold-plated Brass
Current Rating: 5A per Pin (up to 10A on power pins)
Voltage Rating: 600V AC/DC
Housing Material: 316L Stainless Steel
Sealing: Double O-Ring
Footprint: 44 × 24 mm
Body Thickness: 21 mm
Mounting: Threaded with Nut & Washer
Cable: Pre-terminated 13-color PTFE Leads
Waterproof Rating: IP68
Pressure Rating: 60 MPa (~6000 m)
Operating Temperature: -20°C to 80°C
Application: Gigabit Ethernet + High Power + Multi-Sensor/Actuator Flat Penetrators, Ultra-Compact ROV Payloads, Advanced Manipulators, 8K/12K Camera Systems
Certification: ISO9001-2015
Compatibility: SFLPIL13F / SFLPBH13F Females
Place of Origin: Guangdong, China
