HYSF SFLPIL9F Flat 9-core female cable Underwater Connector

Product Description

The HYSF SFLPIL9F packs 9 independent channels in an ultra-thin flat profile with tapered PU overmold, enabling seamless inline splicing and cable termination where round connectors exceed available space. Only 55 mm grip length with integrated strain relief.

Precision 316L stainless steel insert with gold-plated brass sockets, fully encapsulated in black polyurethane. Pre-terminated with 9 color-coded PTFE leads. Fully supports 1000BASE-T Gigabit Ethernet (two shielded twisted pairs) + 5 additional power/sensor/control lines.

The definitive choice for next-generation flat ROV umbilicals, AUV high-resolution camera feeds, Ethernet + multi-sensor chains and deepsea hybrid flat cables requiring maximum channels in minimal cross-section. ISO9001-2015 certified with 100 MPa burst validation and 1000+ mating cycles under pressure.

Product Parameter

Model: SFLPIL9F

Brand: HYSF

Type: Flat 9-Core Female Inline Cable

Gender: Female

Pin Count: 9

Contact Material: Gold-plated Brass

Current Rating: 8A per Pin

Voltage Rating: 600V AC/DC

Housing Material: 316L Stainless Steel + PU Overmold

Sealing: Double O-Ring + Face Seal

Body Profile: 44 × 24 mm

Grip Length: 55 mm

Cable: 9 × 24 AWG PTFE Leads (color-coded)

Overmold: Black Polyurethane (PU)

Waterproof Rating: IP68

Pressure Rating: 60 MPa (~6000 m)

Operating Temperature: -20°C to 80°C

Application: Gigabit Ethernet + Multi-Power + Multi-Sensor Flat Tethers, High-Resolution Camera Chains, Ethernet + Multi-Sensor Umbilicals, Deepsea Flat Inline Splicing

Certification: ISO9001-2015

Compatibility: SFLPBH9M Males

Place of Origin: Guangdong, China
