SMCIL2M is a 2-pin male inline waterproof cable connector designed for ROVs and subsea equipment. Seacon-style with IP68 sealing and tested to 10,000 PSI, it ensures marine-grade performance for micro underwater systems and inline power applications.
The SMCIL2M 2Pin Marine Inline Subsea Connector is designed for professional underwater applications such as ROVs, AUVs, and marine sensors. As a Seacon-style male waterproof cable socket, it supports reliable inline power and signal transmission with an IP68 sealing rating and pressure resistance up to 10,000 PSI. With current ratings up to 10A per contact, a voltage rating of 300V AC RMS, and low contact resistance below 0.01 ohm, this connector delivers robust performance under extreme underwater conditions. Constructed from high-quality corrosion-resistant materials, it ensures durability in marine environments. Suitable for wet-mate applications with temperature ratings from -4°C to 60°C (25°F to 140°F).
Brand: HYSF
Model Number: SMCIL2M
Type: Marine Waterproof Inline Male Connector
Pins: 2 Pins
Shape: Micro Circular Series
Waterproof Rating: IP68
Mated Pressure Rating: Up to 10,000 PSI / 689 Bar
Voltage Rating: 300V AC RMS
DC Rating: 85% of AC Voltage
Current Rating: 10A per contact (max 20A per connector)
Insulation Resistance: > 200 MΩ
Contact Resistance: < 0.01 Ω
Temperature Rating (Water): -4°C to 60°C (25°F to 140°F)
Interface Type: AC/DC
Housing Material: Marine-grade Plastic or Optional Alloy
Contact Material: Gold Plated Brass
Location Pin: Stainless Steel AISI 316
Gender: Male
Application Range: ROVs, AUVs, Subsea Sensors, Underwater Lighting, Marine Data Transmission
Custom Processing: Supported (Cable integration, pin count, housing type)
Place of Origin: China
