HYSF SS-LOCKCAP Custom Stainless Steel Locking Cap (MCBH/MCIL Series, IP68)

Product Description

The HYSF SS-LOCKCAP is a **successfully customized stainless steel locking cap** precision-machined from **316L marine-grade stainless steel** to provide secure, vibration-resistant mating for MCBH/MCIL series underwater connectors. Featuring a **knurled grip** and **internal threaded sleeve**, it locks over standard connector coupling nuts, preventing accidental disconnection during ROV thruster operation, AUV docking, or subsea tool deployment.

Equipped with a **captive Viton O-ring** and **tether eyelet**, it maintains **IP68 sealing** when installed and allows attachment to the cable or housing for loss prevention. The passivated finish ensures maximum corrosion resistance in saltwater. Compatible with all HYSF/Subconn® MCBH/MCIL sizes (2–12 pin), with optional color-coded anodizing or laser-etched serial numbers.

This locking cap was developed for mission-critical applications where connector integrity is paramount. HYSF offers full customization in thread size, tether length, grip texture, and material (titanium option). ISO9001-2015 certified and field-proven in offshore energy and defense deployments.

Product Parameter

Model: SS-LOCKCAP

Brand: HYSF

Type: Custom Stainless Steel Locking Cap

Material: 316L Stainless Steel (Passivated)

Thread: M16–M30 (Matches MCBH/MCIL Series)

Seal: Captive Viton O-Ring

Tether: Integrated Eyelet + Optional SS Wire Lanyard

Grip: Knurled for High-Torque Hand Tightening

Waterproof Rating: IP68 (When Installed)

Pressure Rating: 60 MPa (8702 PSI / ~6000 m)

Operating Temperature: -40°C to 100°C

Compatibility: All MCBH/MCIL Connectors (2–12 Pin)

Application: ROV Thruster Links, AUV Docking, Subsea Tooling, High-Vibration Power/Signal

Certification: ISO9001-2015

Customization: Thread size, tether length/type, color anodizing, laser marking, titanium upgrade

Features: Vibration-Proof Lock, Loss-Prevention Tether, Corrosion-Proof

Place of Origin: Guangdong, China
