HYSF UW-LIGHT-LED is a cost-effective custom underwater LED light with 316L stainless steel housing and imported LED chips. Includes integrated waterproof penetrator connector, IP68-rated to 60 MPa (8702 PSI), ideal for ROV illumination, subsea inspections, and deepwater operations up to 6000m.
The HYSF UW-LIGHT-LED is a successfully customized high-value underwater LED lighting solution featuring a durable **316L stainless steel housing** for exceptional corrosion resistance in saltwater. Equipped with **premium imported LED chips** delivering 1000+ lumens of bright white light (5000K–6000K), it's designed for superior visibility in low-light subsea environments—perfect for ROV manipulator work, pipeline inspections, and deepsea biological studies.
Integrated with a **custom waterproof penetrator connector** (MCBH-compatible) for seamless cable feed-through, it supports dimmable operation and PoE compatibility. The anodized aluminum reflector and tempered glass lens ensure optimal beam angle (60°–120° custom) and pressure resistance to **60 MPa (8702 PSI / ~6000 m depth)**. IP68 sealed with triple O-rings, operating from -10°C to 70°C.
Engineered for **ultra-high cost-performance ratio**, this light offers professional-grade features at an accessible price point. HYSF provides full customization in lumen output, color temperature, beam angle, and connector type. ISO9001-2015 certified and proven in commercial offshore deployments.
Model: UW-LIGHT-LED
Brand: HYSF
Type: Custom Underwater LED Illumination with Penetrator
Housing Material: 316L Stainless Steel (Anodized)
LED Chips: Imported High-Brightness (e.g., Cree/Osram)
Lumen Output: 1000+ Lumens (Customizable)
Color Temperature: 5000K–6000K White
Beam Angle: 60°–120° (Adjustable Reflector)
Connector: Integrated Waterproof Penetrator (MCBH/IL Compatible)
Pressure Rating: 60 MPa (8702 PSI / ~6000 m)
Waterproof Rating: IP68 (Triple O-Ring Seal)
Operating Temperature: -10°C to 70°C
Power Supply: 12–24V DC, 10–20W (Dimmable)
Interface: Power + Optional Dimming Signal
Application: ROV Lighting, Subsea Inspections, Deepsea Exploration, AUV Illumination
Certification: ISO9001-2015
Customization: Lumen rating, beam pattern, color temp, connector pins, mounting bracket
Value Proposition: Ultra-High Cost-Performance Ratio
Place of Origin: Guangdong, China
